Ironcloud Chevy Astro & GMC Safari Driver Seat Swivel

Van Seat Swivel Base with Slop-Free Locking Design

This seat swivel base is designed to allow a factory manual seat to rotate inside the vehicle while maintaining the original seat height and driving position. It is commonly used in campervan and work van conversions to improve interior functionality by turning the seat toward the living or work area when parked. The swivel is built for stable operation on the road and smooth rotation when unlocked, without requiring ongoing maintenance.

Important: This swivel is not directly compatible with electric seats unless manual seat tracks are installed. GEN-I vans (1985–1994/5) require a GEN-II (1996+) seat belt buckle, as the GEN-I buckle is integrated into the seat base.

Key Features

• Maintains factory seat height and pitch: Preserves original seating geometry so driving ergonomics remain unchanged.
• Slop-free locking mechanism: Uses a threaded lock design to eliminate wobble during driving and when locked in position.
• Offset swivel design: Allows full seat rotation with the vehicle door closed in standard configurations.
• Multiple locking detents: Provides six indexed seating positions at 0°, 90°, 165°, 180°, 195°, and 270°.
• Maintenance-free bearing system: Built with a sealed unit-bearing design that does not require lubrication or adjustment.
• Complete installation kit: Includes mounting hardware and installation instructions.
• Straight-cost shipping: Shipped without markup using a “you pay what we pay” pricing approach.

Specs & Details

• Seat height change: None (maintains stock height)
• Swivel positions: 0°, 90°, 165°, 180°, 195°, 270°
• Bearing type: Maintenance-free unit bearing
• Seat type compatibility: Manual seats (electric seats require manual track swap)
• GEN-I van compatibility: Requires GEN-II seat belt buckle
• Hardware included: Yes
