SDHQ Built Reflex Light Actuator Controller for Micro Switch

Key Features:

• Pre-made relay harness to connect Baja Designs Reflex Light Actuators to a SPDT Momentary Micro Switch.
• 10” long legs, which allow for the wiring to be routed in an organized manner close to the battery and power module.
• The pink wire is the signal for downward movement of the light, and the purple wire is the signal for upward movement of the light.
• The white wire connects to the white wires on the 02-1206-WP2 harness, and the grey wire connects to the black wires on the 02-1206-WP2 harness.
• There is a 10A inline-fuse Red wire for providing power to the relays and a black wire for providing ground to the relays.
